Add optional image to connectors and cables ( #153 ) ...
This image, with an optional caption below, is displayed in the lower
section of the connector/cable node in the diagram - just above the
notes if present.
This solves the basic part of issue #27 , and is a continuation of
PR #137 that was closed due to changes in the base branch.
